Other variants on request are possible
Prewired
ORIGINAL PACKED
Safeguarding under transparent flap
Why our power distributors?
Our distribution boxes have the best of all Europe:
MENNEKES Sockets
Lapp Cable
Distribution box finds perfect use
in garage, custom shops, construction sites, etc.
| sockets manufacturer | Mennekes |
| wires manufacturer | Lapp Kabel |
| housing manufacturer | TP Electric |
| CEE sockets amount | 1 x 32A 5p 400V IP44 red Type 3451 Mennekes 2 x 16A 5P 400V IP44 red Type 1385 Mennekes protected with SEZ MCBs: 1 x C32A 3P 2 x C16A 3P |
| cam switch | – |
| power consumption meter | 3-phase electronic meter LE-03d F&F |
| 230V 16A sockets amount | 4 x 230V 16A 2p+E IP44 Type 11111 french system Mennekes protected with SEZ MCBs: 2 x C16A 10kA 1P |
| protection againts direct contact | Residual-Current Circuit Breaker SEZ 40A 30mA 4P Typ A |
| plug | – |
| insulated busbar | 3-phase 11 module 12mm2 |
| rail-mounted screw terminal blocks for AL/CU conductors |
Morek MAA5035A10 |
| equipment | set of mounting screws with caps |
| nominal voltage | 230/400V AC 50Hz |
| nominal current | 40A |
| protection degree | IP44 |
| Icc | ≤ 10kA |
| RDF | 0,7 |
| dimensions | 540x300x200mm |
| manufacturer | Doktorvolt |
| Article-No. | DV-0816-F |
| EAN | 5907589330816 |
