1×12 modular flush-mounted distribution board, protected by 8xMCBs and 1xRCCB (VDE-approved), pre-wired Hager electrical box, 356x348x98mm, Doktorvolt DV-6197-PT

A flush-mounted enclosure measuring 356 x 348 x 98 mm, fitted with a single row of 12 modules. Fitted with Doktorvolt safety devices. A high-quality switchboard manufactured using components from leading brands.

HG SERIES | DV-6197-PT | EAN: 5905191016197

Technical specifications

Weight 5,5 kg
Fuses

RCD
Enclosure material

Plastic

356x348x98mm single-row, 12-module flush-mounted distribution board with 8xMCB and 1xRCCB protection from Doktorvolt

A high-quality flush-mounted distribution board manufactured using components from leading brands. A robust construction ensuring durability and reliability in all conditions. The electrical box is pre-wired and protected, fully ready for immediate use.

Maximum attention to safety

A compact flush-mounted distribution box measuring 356x348x98mm. Made from high-quality plastic offering IK07 impact resistance. Ideal for use in, for example, a garage or workshop. The box has insulation class II. A characteristic of this class is the absence of a PE terminal, whilst the box itself features both basic and supplementary insulation. This ensures safety even if one layer of insulation is damaged. The enclosure has an IP30 protection rating. The box is UV-resistant. The enclosure is VDE-certified.

User comfort combined with high-quality workmanship

The box is fitted with one 40A 30mA Type A 3P+N 10kA residual current circuit breaker and eight Doktorvolt 16A 1P 10kA overcurrent circuit breakers. Designed for flush-mounted installation with an installation depth of 89 mm. It features a single row capable of accommodating 12 modules. The box blends perfectly with a variety of interiors thanks to its pure white RAL 9010 finish. Pre-wired with a neutral conductor.

Technical Specifications

General Information

Model: DV-6197-PT

EAN: 5905191016197

Product series designation: HG

Installation type: Flush-mounted

Manufacturer: DOKTORVOLT

Obraz 1

Sockets and Electrical Specifications

Protective equipment:
1 x R CCB 40A 30mA Type A 3P+N 10kA VDE
8 x Overcurrent circuit breaker (MCB) B 16A 1P 10kA VDE

Rated voltage: 400V

Rated frequency: 50 Hz

Rated current: 40A

Conventional short-circuit current: ≤ 10 kA

Connected via a busbar: Yes

Obraz 2

Enclosure and Technical Specifications

Enclosure dimensions with frame (HxWxD): 356x348x98 mm

Installation height: 340 mm

Installation width: 314.50 mm

Installation depth range: 89 mm

Housing material: Plastic

UV resistance: Yes

Protection class: Insulation class II

Mechanical resistance: IK07

Housing colour: Pure white RAL 9010

Number of modules: 12

Number of rows: 1

Neutral terminal block: Yes

Earth terminal block: Yes

With cable entries: Yes

Enclosure protection rating: IP30

Locking type: Snap-lock, without a lock

Glow wire test: 650ºC

Obraz 3

Wiring and Standards

Internal switchboard wiring:
Neutral conductors: H07V-K control cable, 10 mm², blue

Standards and certificates:
PN-EN 61439-1
PN-EN 61439-3

Every product purchased is supplied with a full set of necessary documentation.

Obraz 4

Certification = a guarantee of quality:

DOKTORVOLT products are routinely tested to ensure the highest quality. Once a product has passed these tests, it receives an individual certificate confirming that it has undergone quality control. The company uses a TÜV SÜD-certified system in its production process, which attests to its high quality.

IP rating = greater safety:

The IP rating is an international standard specifying the extent to which an item is resistant to potential hazards. It consists of two digits which indicate the product’s dust resistance and water resistance. Knowing the IP rating allows you to use the product safely and with confidence. An IP30 rating tells us that the device:
– is protected against the ingress of objects larger than 2.5 mm
– is not protected against dripping water, water jets or immersion

A trusted manufacturer:

Doktorvolt® was founded in 2013. This rapidly growing company has established itself on both the Polish and international markets. The company’s headquarters are located in Malichów in the Opole Voivodeship, where it operates a modern production hall and warehouse. The company specialises in the manufacture of construction switchgear, distinguishing itself through quality and reliability. Each switchboard is constructed from high-quality components. The products comply with the safety standards and regulations in force within the European Union.
