➡️ Wallbox EV Charger for safe charging of your electric vehicle within your own property. Extremely compact and easy to use.
✔️ Designed for AC charging up to 22 kW,,
✔️ made with Type 2 socket standard (IEC 62196-2),
✔️ equipped with car communication controller and START/STOP button with LED charging status indication,
✔️ built-in RCD Typ A + RCM module.
➡️ Wallbox EV Charger DOKTOROLT®, equipped with:, wyposażona w:
✔️ Car charging socket Type 2 32A 5P without lock,,
✔️ charge controller,
✔️ START/STOP button with LED indicator light,
✔️ inspection window 12 modules..
✔️ equipped with PG16 cable gland for power cable connection.
|nominal load current||32A/400V AC|
|charging power||22 kW|
|vehicle connection||charging socket Type 2 according to IEC 62196-2|
|smart charge controller||Charging control that supports communication between the station and the connected car. Automatically disables the charging process in the event of an error|
|START/STOP button with LED indicator light||Illuminated main switch with status indicator by flashing pulses|
|cable with connector||Version with cord and permanently connected CEE 16A 400 V plug, cord 1m|
|residual current protection||RCD Typ A + RCM module|
|Technical data of the housing:|
|housing dimensions (without sockets)||355 x 255 x 125 mm|
|housing material||Plastic (suitable for outdoor use)|
|Front/rear panel colour||grey/black|
|ambient temperature||-20 °C ~ +50 °C|
|Protection against ingress of solid foreign objects and against water penetration||IP44|
|Resistance to UV radiation||yes|
|Manufacturer’s certificates and standards||TÜV SÜD, ISO 9001:2015, CE, IEC 61439 EN 62196-2|
|manufacturer’s serial number||WALLBOX Doktorvolt|
