eXT 32A 16A construction distribution board, camping 2x16A 8×230 Schuko DV-2346-D
eXT SERIES | | EAN: 5907589332346
Technical specifications
| Weight | 6 kg |
|---|---|
| Fuses | No protection |
| CEE current rating | 32A |
| CEE Number of poles (modules) | 3P |
| CEE voltage | 230V |
| Socket type | Type F (Schuko) |
| Enclosure material | Plastic |
eXT 32A 16A construction distribution board, camping 2x16A 8x230V Schuko Mennekes Doktorvolt®
German Schuko socket system
⭐⭐⭐⭐⭐
➡️ eXT 32A 16A camping distribution board, 2x16A, 8x230V, Doktorvolt®, advantages:
✔️ robust and compact housing made from the highest quality materials,
✔️ fitted with 2x 16 A camping sockets, eight 8x 230 V 16 A sockets, and power sockets: 1x 16 A 400 V and 1x 32 A 400 V from Mennekes,
✔️ cabling and sockets sourced from reputable manufacturers of electrical equipment,
✔️ IP 65 protection rating,
✔️ ready for connection,
➡️ Doktorvolt® eXT 32A 16A camping electrical distribution board (2x16A, 8x230V), applications:
✔️ On construction sites and during roadworks,
✔️ for industrial premises,
✔️ in workshops and garages where equipment needs to be connected to a heavy-duty socket,
✔️ during DIY house building,
✔️ for supplying electricity to green spaces and large-scale outdoor events.
➡️ The construction switchboard shown here is equipped with:
✔️ two 8x 230 V 16 A sockets with IP 54 protection rating,
✔️ power sockets: 1x 400 V 16 A and 1x 400 V 32 A, with an IP 44 protection rating,
✔️ 2x 16 A camping sockets with an IP 44 protection rating,
✔️ cabling.
➡️ Doktorvolt® has implemented a TÜV SÜD-certified management system in its switchboard manufacturing process:
✔️ a guarantee of high quality,
✔️ transparent flow of information,
✔️ a guarantee of safety,
✔️ assured good customer service.
| Number of 230V 16A sockets |
8x 230V 16A IP54 blue Type 11011 Schuko Mennekes |
| Number of power sockets |
1 x 32A 5-pole 400V IP44 red Type 3451 Mennekes 1 x 16A 5-pole 400V IP44 red Type 1385 Mennekes 2 x 16A 3-pole 230V IP44 Type 1366 Mennekes (camping)
|
| cable gland | PG-21 13–18 mm |
| connector | busbar connector 2.5–35 mm² grey-blue-yellow, 10-hole 5-pole terminal block MAA5035A10 Morek |
| end cap for busbars 3F 12mm² Z-12/3F | Yes |
| rated voltage | 230/400 V AC 50 Hz |
| rated current | 144A |
| protection class | IP44 |
| Icc | ≤ 10kA |
| RDF | 0.7 |
| dimensions | 720 × 290 × 200 mm |
| manufacturer | Doktorvolt |
| Model | DV-2346-D |
| EAN |
5907589332346 |
