RCCB residual current circuit breaker 10kA 2P 40A 30mA VDE Type A Doktorvolt DV-4513
A 10kA residual current device (RCD) by Doktorvolt. Manufactured from the highest quality materials. It provides protection against the effects of short circuits. These RCDs are VDE-certified, confirming their compliance with international electrical safety standards.
RESIDUAL CURRENT CIRCUIT BREAKERS TYPE A | | EAN: 5905191014513
Technical specifications
| Weight | 0,218 kg |
|---|---|
| Residual current | 30mA |
| Number of poles | 2P |
| Rated current | 40A |
Doktorvolt RCCB Residual Current Circuit Breaker 10kA 2P 40A 30mA
This residual current circuit breaker is manufactured from the highest quality materials to ensure user safety. Its function is to detect any difference in current between the live and neutral wires. It holds VDE certification confirming compliance with international electrical safety standards.
High-quality construction
The DV-4513 RCCB, with operating characteristic class A and a rated current of 40A, provides effective protection for electrical installations in industry and the construction sector. Equipped with a ‘Test’ button located on the top of the circuit breaker, it allows for quick and convenient functional testing. It features a labelling option, with a label that can be placed under a plastic flap for better identification. The VDE certificate confirms its high quality and safety in use. An additional advantage is its resistance to short-circuit currents of up to 10 kA, making it the ideal choice for industrial and commercial systems requiring the highest level of reliability.
Technical Specifications
Rated conditional short-circuit current: 10 kA
Rated current: 40 A
Number of poles: 2P(1P+N)
Rated residual current: 30 mA
Rated voltage: 240 V
Operating temperature range: -25 – +40
Protection rating: IP20
Installation: 35 mm DIN rail
Type: A
Frequency: 50/60 Hz
